12" Electric Lightning 70

  • 16Ω
General Characteristics for 8Ω
Nominal Overall Diameter307 mm.12 in.
Nominal Voice Coil Diameter50 mm.2.00 in.
Magnet Weight1450 g50.00 oz
Overall Weight9.92 lbs
Flux Density1.15 T
Voice Coil Winding Depth0.39 in.
Magnetic Gap Depth0.31 in.
Thiele-Small Parameters for 8Ω
Voice Coil DC ResistanceRE6.33 Ω
Resonance FrequencyƒS95.0 Hz
Mechanical Q FactorQMS14.77
Electrical Q FactorQES0.70
Total Q FactorQTS0.67
Mechanical Moving MassMMS29.9 g
Mechanical ComplianceCMS94 µm/N
Force FactorBxL12.70 Wb/m
Equivalent Acoustic VolumeVAS32.0 lt.
Maximum Linear DisplacementXMAX±1.00 mm
Reference EfficiencynO3.76 %
Diaphragm AreaSD490.9 cm2
Losses Electrical ResistanceRES133.3 Ω
Voice Coil Inductance @ 1kHzLE0.60 mH
Constructive Characteristics for 8Ω
MagnetFerrite
Voice Coil WindingAluminum
Voice Coil FormerKapton
Cone MaterialPaper
Surround MaterialIntegrated Paper
Dust Dome MaterialNon-treated Cloth
Basket MaterialPressed Sheet Steel
Surround TreatmentYes
Electrical Characteristics for 8Ω
Nominal Impedance8 Ω
Rated Power70 W
Musical Power140 W
Sensitivity@1W,1m99.0 dB
General Characteristics for 16Ω
Nominal Overall Diameter307 mm.12 in.
Nominal Voice Coil Diameter50 mm.2.00 in.
Magnet Weight1450 g50.00 oz
Overall Weight9.92 lbs
Flux Density1.15 T
Voice Coil Winding Depth0.39 in.
Magnetic Gap Depth0.31 in.
Thiele-Small Parameters for 16Ω
Voice Coil DC ResistanceRE11.94 Ω
Resonance FrequencyƒS93.0 Hz
Mechanical Q FactorQMS14.50
Electrical Q FactorQES0.93
Total Q FactorQTS0.88
Mechanical Moving MassMMS28.3 g
Mechanical ComplianceCMS103 µm/N
Force FactorBxL14.56 Wb/m
Equivalent Acoustic VolumeVAS35.3 lt.
Maximum Linear DisplacementXMAX±1.00 mm
Reference EfficiencynO2.92 %
Diaphragm AreaSD490.9 cm2
Losses Electrical ResistanceRES185.7 Ω
Voice Coil Inductance @ 1kHzLE0.80 mH
Constructive Characteristics for 16Ω
MagnetFerrite
Voice Coil WindingAluminum
Voice Coil FormerKapton
Cone MaterialPaper
Surround MaterialIntegrated Paper
Dust Dome MaterialNon-treated Cloth
Basket MaterialPressed Sheet Steel
Surround TreatmentYes
Electrical Characteristics for 16Ω
Nominal Impedance16 Ω
Rated Power70 W
Musical Power140 W
Sensitivity@1W,1m98.1 dB
JC12-70EL
12"
,
70 watts
  • Ohms:
  • 16Ω

The Electric Lightning's tone is straightforward and powerful with fat lows, throaty mids and crisp, bright highs. It is a true "in your face" Rock n' Roll speaker that can handle the heaviest of playing styles and is designed for loud applications.

Lows:Mids:Highs:Overdrive:
FatAggressiveBrightCrunchy
Straightforward, powerful tone with fat lows, throaty mids and crisp, bright highs. It responds to overdrive distortion with a commandingly strong and well-defined crunch.
Sound Samples:
Clean Sound Sample00:15https://www.jensentone.com/sites/jensentone.com/files/sound_samples/jc12-70el_clean.mp3
Overdriven Sound Sample00:15https://www.jensentone.com/sites/jensentone.com/files/sound_samples/jc12-70el_overdriven.mp3
Blues Sound Sample00:49https://www.jensentone.com/sites/jensentone.com/files/sound_samples/jc12-70el_blues.mp3
Country Sound Sample00:35https://www.jensentone.com/sites/jensentone.com/files/sound_samples/jc12-70el_country.mp3
Jazz Sound Sample00:43https://www.jensentone.com/sites/jensentone.com/files/sound_samples/jc12-70el_jazz.mp3
Metal Sound Sample00:55https://www.jensentone.com/sites/jensentone.com/files/sound_samples/jc12-70el_metal.mp3
Rock Sound Sample00:43https://www.jensentone.com/sites/jensentone.com/files/sound_samples/jc12-70el_rock.mp3
Having trouble playing our sound samples? Click here to access the files directly.
Frequency Response Charts:
  • 16Ω

User Reviews

Click Here to submit your own review for Jensen Speakers!

I love this speaker! I play mostly metal and hard rock in Drop C tuning, and the Jensen Electric Lightning keeps up in a closed back 1 x 12" cab. Articulation, pick attack, note separation, and depth all from the same speaker! Also, the tone of the Electric Lightning is unlike any other guitar speaker I've ever heard, which keeps me from sounding like everybody else.

I play in an eclectic punk band and I use two Electric Lightning with a Marshall 100 tube amp and it sounds killer most of the sound men think I am too loud but the rest of the band and the audience loves it! Thanks Jensen!
